Flexible Active Line Array System , Conference Audio System Speaker
Box
ABOUT CVR:
CVR PRO AUDIO is a cutting edge professional audio speaker
manufacturer specializing in designing and manufacturing
professional audio systems,including PA speaker,indoor and outdoor
line array speaker,subwoofer,floor monitor, power amplifier and
speaker management system. We provide these products for indoor and
outdoor events, stadiums, churches, performing arts venues,
theatres,conference rooms, meeting halls, and any space where audio
system are needed.
DESCRIPTION and APPLICATION
W-82C is a line array system which is made of a 8＂woofer, a
1.75＂titanium compression driver and high performance low
distortion compression driver with innovative horn design of wave
phase philosophy. Wherever low frequency extension is required, a
W-82C will integrate seamlessly with W-15C or W-15CP line array
sub-bass system in a standard configuration. Each enclosure is
equipped with rigging system, allowing flown array to be
constructed rapidly and safely. W-82C is very versatile and
scalable for a wide range of applications in touring performance,
corporate and fixed installation fields.
W-15C/W-15CP is a dedicated high performance sub-bass system
designed to augment the low frequency output of W-82C. W-15C/W-15CP
is a sub-bass enclosure which must be flown with W-82C. So its
physical dimensions are identical to the W-82C and it is equipped
with the same proprietary rigging system. It features with a
15＂woofer with magnet structure and suspensions engineered for
maximum linear excursion. The W-15CP with Bluetooth features a
highly efficient power amp module and incorporated DSP.
| Frequency Response | 70Hz-20KHz±3dB |
| 40Hz-500Hz±3dB(W-15C/W-15CP) |
| Power handling | 250W(RMS)500W(PEAK) |
| 500W(RMS)1000W(PEAK)(W-15C/W15CP) |
| Power amp | 2X600W/4ohm + 1X900W/8ohm(W-15CP) |
| Amplifier type | Switching power amp, class D circuit |
| Other functions | Bluetooth,DSP (W-15CP) |
| Sensitivity | 96dB(1W@1M) |
| 106dB(1W@1M)(W-15C/W15CP) |
| Max@S.P.L | 116dB(PEAK/1M) |
| 130dB(1W@1M)(W-15C/W15CP) |
| LF section | 1×8"(210mm)woofer 50mm(2in)coil |
15"(380mm)woofer 100mm(4in)coil
(W-15C/W-15CP) |
| HF section | 1×1.75"compression driver with44mm
titanium diaphragm |
CVR PRO AUDIO aims to:
Become your most trusted and reliable manufactory
Provide high quality pro sound equipment at realistic prices
Provide outstanding designs together with delicate finished
Provide meticulous and considerate service for clients
See more at: www.cvr-audio.com
