Functional Line Array Sound Column Speakers 12 Inch PA System For
Club
T-12 is a bi-amps, line array system which is made of one 12＂, two
1.75＂titanium neodymium compression drivers and high-performance
low-distortion compression driver with innovative horn design of
waves phase philosophy. It is a zero interfere line array with
multi- speaker combined to produce accurate directivity and maximum
dynamic impact. Each enclosure is equipped with rigging system,
allowing flown array to be constructed rapidly and safely. T-12 is
a compact line array enclosure designed to bring superb line array
performance to large stadiums, big outdoor concerts and commercial
events. The switchable one or bi-amplified two way cabinet is very
efficient, It meets the need for a high power, high bass impact
system that is versatile and scalable for a very wide range of
applications in the live sound, corporate and fixed installations.
Model | T-12 |
Type | Array system |
Frequency Response | 55Hz－20kHz±3dB |
Power handling | 400W(RMS)800W(PEAK) |
Sensitivity | 100dB(1W@1M) |
Max@S.P.L | 126dB(PEAK/1M) |
LF section | 12"(310mm) woofer 75mm(3in)coil |
Nominal impedance | 8 ohm |
HF section | 2×1.75＂compression driver 44mm titanium diaphragm |
Nominal impedance | 8 ohm |
Output section | 2-channel |
Dispersion pattern | 110°H×5°V |
Finish | Black paint |
Speaker cables | Passive 1(+),1(-). Built in
crossover
Bi-AMP LF 1(+),1(-)
HF 2(+),2(-) |
Competitive Advantage:
1. High quality speaker drivers, high power handling capability,
good sound quality, flyware easy for operation, beautiful mesh
grille design,highest standards of workmanship and quality control.
2. A good solution for all sizes of indoor/outdoor live event,and
indoors applications like disco,
night club, conference,school auditorium, and places of worship;
3. To avoid damage and scratch during transport,according to
customers’requirement,we can put the items in extra cost flight
cases.
4. Established in 2005, CVR PRO AUDIO has forged a reputation as
one of the nation's most experienced and reliable manufacturer of
pro sound equipment.
ABOUT CVR:
CVR PRO AUDIO is a cutting edge professional audio speaker
manufacturer specializing in designing and manufacturing
professional audio systems,including PA speaker,indoor and outdoor
line array speaker,subwoofer,floor monitor, power amplifier and
speaker management system. We provide these products for indoor and
outdoor events, stadiums, churches, performing arts venues,
theatres,conference rooms, meeting halls, and any space where audio
system are needed.
CVR PRO AUDIO aims to:
Become your most trusted and reliable manufactory
Provide high quality pro sound equipment at realistic prices
Provide outstanding designs together with delicate finished
Provide meticulous and considerate service for clients
See more at: www.cvr-audio.com
