Plastic Active Line Array Speaker System 8 Inch Powered Speakers

Product Categories

Guangzhou CVR Pro-Audio Co., Ltd

Contact Now

Plastic Active Line Array Speaker System 8 Inch Powered Speakers

Ask Lasest Price
Brand Name :	CVR
Model Number :	W-82C W-15CP
Certification :	CE,RoHS
Price :	Negotiation
Payment Terms :	D/A, D/P, L/C, Western Union
Supply Ability :	1000 Pieces Per Month
Delivery Time :	5--8 Work Days

Add to Cart

Product Details
Company Profile

Plastic Active Line Array Speaker System 8 Inch Powered Speakers

DESCRIPTION and APPLICATION:

W-82C is a line array system which is made of a 8＂woofer, a 1.75＂titanium compression driver and high performance low distortion compression driver with innovative horn design of wave phase philosophy. Wherever low frequency extension is required, a W-82C will integrate seamlessly with W-15C or W-15CP line array sub-bass system in a standard configuration. Each enclosure is equipped with rigging system, allowing flown array to be constructed rapidly and safely. W-82C is very versatile and scalable for a wide range of applications in touring performance, corporate and fixed installation fields.

W-15C/W-15CP is a dedicated high performance sub-bass system designed to augment the low frequency output of W-82C. W-15C/W-15CP is a sub-bass enclosure which must be flown with W-82C. So its physical dimensions are identical to the W-82C and it is equipped with the same proprietary rigging system. It features with a 15＂woofer with magnet structure and suspensions engineered for maximum linear excursion. The W-15CP with Bluetooth features a highly efficient power amp module and incorporated DSP.

Model	W-82C ＆ W-15C/W-15CP(Active)
Type	Line arry system
Type	line arry sub-bass system(W-15C/W-15CP)
Frequency Response	70Hz-20KHz±3dB
Frequency Response	40Hz-500Hz±3dB(W-15C/W-15CP)
Power handling	250W(RMS)500W(PEAK)
Power handling	500W(RMS)1000W(PEAK)(W-15C/W15CP)
Power amp	2X600W/4ohm + 1X900W/8ohm(W-15CP)
Amplifier type	Switching power amp, class D circuit
Other functions	Bluetooth,DSP (W-15CP)
Sensitivity	96dB(1W@1M)
Sensitivity	106dB(1W@1M)(W-15C/W15CP)
Max@S.P.L	116dB(PEAK/1M)
Max@S.P.L	130dB(1W@1M)(W-15C/W15CP)
LF section	1×8"(210mm)woofer 50mm(2in)coil
LF section	15"(380mm)woofer 100mm(4in)coil (W-15C/W-15CP)
HF section	1×1.4" neodymium compression driver with44mm titanium diaphragm
Nominal impedance	8 ohm(W-82C)& 8 ohn (W-15C/W-15CP)
Output section	2-channel
Dispersion pattern	110º H×9º V
Surface finish	Black paint
Array design	Arrays of less than 3×W-82C will provide poor dispersion control and are neither recommended nor supported
Speaker cables	1(+)1(-) Built in crossover
Rigging system	Please refer to the W-82C user's manual before any operation
Input connectors	2×NL4MP speakon
Recommend crossover	70Hz-20KHz
Recommend crossover	40Hz-100Hz(W-15C/W-15CP)
Dimensions	544×245×375mm(W×H×D)
Dimensions	515×450×611mm(W×H×D) (W-15C/W-15CP)
Package dimensions	615×315×445mm/0.09cbm
Package dimensions	585×520×680mm/0.22cbm (W-15C/W-15CP)
Enclosure	HLPE(W-82C)/Plywood(W-15C/W-15CP)
Net weight	12.5kg(W-82C)/34kg(W-15C)/40kg(W-15CP)
Gross weight	14.5kg(W-82C)/37kg(W-15C)/43kg(W-15CP)

CVR PRO-AUDIO,LET YOUR EARS BE THE JUDGE !

Guangzhou CVR Pro Audio Co., Ltd is specialized in researching, developing and manufacturing high quality pro audio equipment.Boasting talented professional employees and leading technology, we manufacture and supply a compreh ensive range of professional equipment including line array system, proloudspeaker, subwoofer, minitor speaker and power amplifier. CVR pro audio products have been far sales to over 100 countries abroad,enjoying high reputations and popularitys.Our own modern industrial factory occupies over 5000 square meters, equiped with advanced processing lines and sound online testing systems. R&D department, production, QA, engineering, overseas sales department, domestic sales department and aftersales service are all running well under strict management constructive guidelines.

Brand Promises:

To get the best goods with least money is not only customers favorites,but also CVR's target.

Quality Wood Enlosure: Birch Plywood and Plywood.
Detailed cutting and Design: Proffessional design for driver,frequency divider,tweeter, horn and cabinet.
Environment protection spray-paint: nontoxic water paint which is environment protected and werable.
CE&RoHS certificate: for all products
Strictly test before delivery: All products are under the examination of our engineer team before dilivery.
Strong packing: Quality carton boxs with firm belt and flight cases are required.
Fast lead time: Sample order in stock and normally within two weeks for bulk production.
Good After-sale service: All products have one year warranty and lifetime follow-up service.Parts will be free from maintenance within warranty period. Any inquiries will be replied within 24 hours.
